Direct Answer
For a quarter-turn actuator with NAMUR accessory references, compare the actual pilot-valve and feedback-device interface drawings. A NAMUR label alone does not prove cross-brand interchangeability. Confirm valve mounting, torque through travel, required return behavior, air supply and the exact accessory configuration before ordering.
Why Packaging OEMs Standardise on the NAMUR Interface
Packaging lines for filling, capping, labelling and cartoning repeat the same quarter-turn motion many times per shift. Using a common NAMUR accessory footprint lets an OEM keep one valve-island concept, one spare-parts list and one drawing set across several machine sizes.
Treat the accessory interface and the actuator-to-valve mounting as separate checks. Obtain the mounting/port dimensions, shaft details, torque data and installation drawing for the exact models before comparing alternatives.
Selection and Buyer Checklist
| Parameter | What to confirm | Why it matters |
|---|---|---|
| Accessory interface | Exact pilot-valve port pattern and switch-box mounting drawings | Checks the actual port, shaft and fastening compatibility |
| Valve mounting | EN ISO 5211 flange size and torque designation | Prevents mismatch between actuator output and valve stem |
| Output torque | Break torque plus safety margin, at the stated supply pressure | Under-sized actuators stall; over-sized units waste air |
| Fail-safe position | Spring-return or double-acting; open or closed on air loss | Defines machine behaviour on air or power loss |
| Air supply | Working pressure and ISO 8573-1 purity class | Moisture, oil and particles cause premature seal wear |
| Duty | Cycles per minute, cycles per year, ambient temperature | Continuous packaging duty is more demanding |
| Documentation | Drawing, torque curve, material list, conformity documents | Needed for the machine technical file |
| Traceability | Model code, batch or date marking, seal-kit number | Keeps maintenance predictable |
What EU Buyers Should Verify in Writing
EU buyers placing packaging machinery on the market work under Machinery Regulation (EU) 2023/1230, which applies from 20 January 2027 and replaces the Machinery Directive. Pneumatic actuators and solenoid valves are usually components rather than finished machines, but the machine builder still needs consistent component data for the technical file and risk assessment.
Confirm three points in writing before order release:
- the fail-safe position on air or power loss, agreed between machine builder and end user;
- the compressed-air purity class the actuator is specified for, so compressor and dryer are sized on the same basis;
- the documentation package the supplier will issue for the ordered models.
Approval and marking details vary by model and market, so treat certification claims as unconfirmed until the supplier issues them for the exact model code.
FAQ
Do NAMUR actuators fit any pneumatic valve?
No. Compare the exact accessory port/mounting drawings and the separate actuator-to-valve flange, stem and coupling dimensions. A family label does not prove every interface matches.
Can I use a NAMUR solenoid valve from another brand?
It needs verification. Compare the mounting and port drawings, seals, function, voltage, flow, pilot supply and manual override for both exact models; do not assume an adapter-free fit from the NAMUR label.
What is the typical MOQ and lead time?
MOQ and lead time depend on model, size and configuration. Send the model code, quantity and required delivery window for a firm answer.
What information do you need to confirm the model?
Valve type and size, required torque, air supply pressure, single-acting or double-acting, fail-safe position, mounting standard, solenoid voltage and connection, and ambient temperature where the line runs hot or cold.
Can I get a drawing or photos before ordering?
Yes. Request a dimensioned drawing, torque table and photos of the configuration. Checking mounting dimensions against your valve drawing before order release avoids returns.
Do you supply samples?
Sample quantities are usually possible for standard configurations. Confirm samples together with MOQ and lead time, because customised units may not be available as samples.
Next Step
If you are specifying a NAMUR-standard pneumatic actuator for a filling, capping or cartoning line, send the valve type, required torque, air supply pressure and fail-safe position. Kailing Fluid can review the accessory interface and mounting arrangement and reply with a model suggestion, drawing and delivery window. Current product ranges are listed at www.kailingfluid.com.
