Series
KLF, Dust collector, Pulse jet, Environmental equipment
Applications
Pulse-jet cleaning and control components for dust collectors and environmental equipment.
RFQ details
Valve size, tank pressure, pulse frequency, coil voltage, installation method, quantity and delivery timing.
Parameter shortlist
Model / series: KLF, pulse-jet and dust-collector valve series.; Media: Dry compressed air for pulse-jet cleaning systems.; Materials and seals: Aluminum alloy or series-specific body; diaphragm and seal material matched to pulse frequency and air quality.; Voltage / electrical items: Common pilot coil options include DC 24 V and AC 110/220 V.; Pressure range: General review range: 0.4 to 0.8 MPa tank pressure; confirm by collector design.; Temperature range: General review range: -10 to 80 C, depending on diaphragm and installation environment.
Typical conditions
Baghouse dust collection; Environmental equipment pulse cleaning; Cement, powder, woodworking or surface-treatment equipment
Selection warnings
Do not select only by port diameter; match tank pressure, pulse volume and diaphragm size.; Poor air quality can shorten diaphragm life.; Confirm mounting style before replacing existing pulse valves.
Document support
Ask by model for catalog, dimensions, installation method, matching accessories and certificate scope.
